Fan Coil Unit
A terminal device for central air conditioning water systems. Through chilled/hot water circulation and air heat exchange, it regulates indoor temperature and serves as an essential component of water-based central air conditioning systems.
1 / 2Overview
Fan Coil Unit
An important terminal unit in central air conditioning water systems. Installed in indoor spaces, it achieves cooling and heating by exchanging heat between indoor air and chilled/hot water supplied by the main unit. The unit supports multiple installation methods, including concealed ceiling installation and exposed installation. With concealed installation, only air outlets remain visible indoors, maintaining a clean and aesthetic interior while enhancing comfort. It is widely used in hotels, office buildings, commercial complexes, and other building applications.
Applications
Key Features
Central Air Conditioning Terminal Unit
A key indoor terminal device for water-based central air conditioning systems, providing efficient indoor temperature regulation.
Concealed Ceiling Installation
Supports ceiling-mounted concealed installation, reducing equipment exposure and maintaining a clean and elegant interior space.
Cooling & Heating Integration
Works with chilled/hot water source units to provide both cooling and heating functions.
Flexible Adaptation
Supports horizontal, vertical, concealed, and exposed installation methods to meet different space requirements.
High-Efficiency Heat Exchange
Uses three-row coil design and hydrophilic fins to improve heat exchange efficiency and achieve rapid temperature adjustment.
Easy Maintenance
Features a detachable coil design for convenient cleaning and maintenance, extending equipment service life.
Specifications
Fan Coil Unit
- Equipment Type
- Central Air Conditioning Water System Terminal Unit
- Cooling Capacity Range
- 1.8–12.6 kW
- Airflow Range
- 340–2380 m³/h
- Installation Methods
- Horizontal / Vertical / Concealed / Exposed
- Motor Type
- Standard Fan Motor / DC Brushless Motor
* Specifications are for reference only; final selection prevails.
